Direct cooling refrigeration machine

The direct cooling refrigeration machine adopts refrigerant direct evaporation, and the cooling method is phase change refrigeration. Compared with the temperature difference cooling of liquid cooling, the cooling speed is faster, the energy efficiency is higher, the equipment has no circulation system, and the external dimensions are more compact!

1. Customizable temperature range from -150 ℃ to 35 ℃
2. Overall foam insulation, good insulation effect, and no condensation on the surface
3. Control evaporation pressure and high stability.
4. Allow customization of non-standard control systems

Consult immediately

OUR
ADVANTAGE

products

PROTECO

See the parameters clearly

Name

Device Name
Equipment model
External dimensions (length * width * height)
Refrigeration method
compressor
evaporator
Intermediate heat exchanger
Reheater
condenser
Refrigeration valve components
cryogen
Temperature sensor
Pressure sensor
Electrical components
PLC
operation panel
Equipment voltage
Distribution power

Parameter Function Description

Direct cooling low-temperature refrigeration machine
PTZL-F05W
650 * 400 * 380mm (try to make the size as small as possible)
Double compressor cascade water cooling
Taikang fully enclosed piston compressor (1.5 horsepower * 2 units)
External customer cold plate
High power plate heat exchanger
High power plate heat exchanger
Baode dual system plate heat exchanger
Danfoss/Emerson/Castor
First level R404A, second level R23
T-type thermocouple
Weika, Germany
Schneider
Siemens
7-inch touch screen with Chinese display, easy to operate and intuitive display, capable of displaying and recording temperature curves and test data
AC 220V/1/50Hz
2.4kW

Product recommendations

Non standard customization

It mainly consists of refrigeration system, circulation system, control system, box, etc. The refrigeration system adopts steam compression refrigeration, and the compressor and main refrigeration components are all from internationally renowned brands. Ensure the safe operation of the equipment for external applications that require rapid cooling.

Ultra low temperature freezer

The DLS series low-temperature chiller is mainly composed of refrigeration system, circulation system, control system, box, etc. The refrigeration system adopts steam compression refrigeration, and the compressor and main refrigeration components are all from internationally renowned brands, with stable and excellent performance at the outlet water temperature. The temperature control accuracy can reach ± 0.1 ℃, and optional components can achieve multi-channel output and load, which is energy-saving and environmentally friendly, and easy to operate. And it can achieve multiple alarm functions such as overheating, overload, and water shortage, making remote control convenient. It can control various communication methods such as I/O, RS232, RS485, etc

Low temperature chiller

-135 ℃~+225 ℃, can meet the needs of different temperatures, and can be customized non-standard; Optional precise temperature control form, with a maximum temperature control accuracy of ± 0.1 ℃; Using an efficient heat exchanger, the cooling speed is fast, and it only takes 5 minutes to reach -80 ℃ at room temperature; Optional cooling capacity recovery device to improve energy efficiency and avoid low-temperature condensation water. Optional intake flow automatic control and detection
